Perlite 0.1-1mm

◆ Unexpanded Perlite is processing by crushing, screening of the original perlite ore, we can produce according to the needs of customers into a variety of perlite sand products, the current specifications are :8-12 mesh ,12-18 m
Contact Us
Description

 Unexpanded Perlite is processing by crushing, screening of the original perlite ore, we can produce according to the needs of customers into a variety of perlite sand products, the current specifications are :8-12 mesh ,12-18 mesh ,18-20 mesh ,20-50 mesh ,30-50 mesh ,50-70 mesh ,70-90 mesh ,90-120 mesh and other products.



Chemical property :



SiO2%

Al2O3%

Fe2O3%

CaO %

K2O %

Na2O %

MgO %

H2O %

68~74

±12

0.5~3.6

0.7~1.0

2~3

4~5

0.3

2.3~6.4



Physical property :

Terms

A

B

C

Specific Gravity

2.26

2.4

2.32

Hardness(HV)

648

643

652

Expansion Rate

K0≥15

K0≥15

K0≥18

Expa-temperature(℃)

1000-1200

1050-1250

1200-1300

Pre-heating (℃)

300-400

300-400

350-420



Usage:

(1) 8-12mesh ,12-18mesh ,18-20mesh perlite sand after expansion can be as insulation, thermal insulation material widely used in construction.

(2) 20-50mesh ,30-50mesh pearlite sand by the expansion of steel can be used as a cover agent deslagging agents.

(3) 50-70mesh ,70-90mesh ,90-120mesh pearlite sand can be as expansive as the beer, pharmaceutical agents and use of filtering low-temperature oxygen tank with insulati







 Expanded Perlite specification



Item

Specification

Item

Specification

Specific gravity

0.15-2.4g/cm3

Thermal conductivity

0.032-0.045

Flotage rate%

98Min

Suface glazed rate%

95min

Water absorption%

20-50

1Mpa (Pressure)volume loss%

38-46

Fire resistance

1280-1360degrees

Application temperature

1400max

Cofficient of water permeability

200mm/hr

water-absorbable



420-600KGS/M3

PH

6.5-7.5

Loss in Burning

4-8

Liquid Solubility

<0.1%

Acid solubility

<2%

Refractive index

1483-1506









Perlite filter specification



Iterms



Model

K(fast)

Z(intermediate speed)

M(low speed)

Bulk density (g/cm3)

<0.15

<0.2

<0.25

Relative Velocity(s/100ml)

<30

30~60

60~80

penetration rate (Darcy)

10~2

2~0.5

0.5~0.1

suspended matter (%)

≤15

≤4

≤1

150 mesh screen tailings (%)

≤50

≤7

≤3





Expanded perlite size:

1. Perlite filter aid : 30-50mesh, 50-70mesh, 70-90mesh, 90-120mesh, 120-200mesh 325mesh
2. Expanded Perlite: 60mesh, 100mesh, 120mesh, 150mesh, 0.1-1mm, 0.5-1.5mm1-2mm, 2-4mm3-6mm 4-8mm

3. Horticultural Perlite: 1-2mm, 2-4mm, 1-4mm ,3-5mm.4-8mm

4. Special size is supplied as per customers' demands .



Application:

1. Horticultural Applications

In horticultural applications, perlite is used throughout the world as a componet of soilless growing mixed where it provides aeration and optimum moisture retention for superior plant growth. Other horticultural applications for perlite are as a carrier for fertilizer, herbicides and pesticides and for peletizing seed.

2. Construction applications

Perlite is widely used as a loose fill insulation in masonry construction. Other construction applications include chimney linings, under-floor insulation, gypsum boards, paint texturing, ceiling tiles, and roof insulation boards etc.

3. Industrial Application

Ranging from high performance fillers for plastics to cements for petroleum,water and geothermal wells
